Leitz window system solutions

Leitz takes window development forward

Leitz recognizes market trends. The company has strong relationships with renowned testing institutes and manufacturers of fittings and seals, which means we know what is important when it comes to window construction. Leitz uses this resulting know-how with project partners in the joint development of window and door systems and passes this specialist product knowledge on to its customers.

In order to meet and exceed international requirements, Leitz develops standards for modular window and door systems.


Leitz ClimaTrend Style

Window design for the future

Leitz ClimaTrend Style

Window design for the future

With the ClimaTrend Style, Leitz presents a window system that can be produced economically and fully complies to the market requirements, with slim design and for passive house installations.

Leitz ClimaTrend Style
ClimaTrend Style

Flexibility

A lean look and further design possibilities through

Flexibility

A lean look and further design possibilities through

  • Minimised timber sections
  • Overall width less than 100 mm
  • Desirable glass to frame ratio
  • Various material and colour options for interior and exterior profiles

Efficiency

Economical use of materials, tooling and manufacturing time through

Efficiency

Economical use of materials, tooling and manufacturing time through

  • Modular design of different materials
  • Reduced cutting depths
  • Standardisation of the production steps for wood and wood/aluminium systems
  • PlugTec corner joint (optional dowel construction or slot/tenon)

Sustainability

Future-proof, long lasting and environmentally friendly system through

Sustainability

Future-proof, long lasting and environmentally friendly system through

  • High thermal ratings for energy efficiency and suitable for passive house installations
  • Protection against noise, weather and burglary
  • Glass thickness up to 70 mm
  • Tested and certified to current regulations

Patio Inowa

The high density sliding window and sliding door system

Patio Inowa

The high density sliding window and sliding door system

With strong project partners and technology leaders, a globally unique sliding window and sliding door system was developed. Patio Inowa combines easy handling, high tightness and attractive design for parallel sliding doors and -windows. The clever technology also allows straight, narrow profiles in a modern design.

Patio Inowa window & sliding door system
Patio Inowa window & sliding door system

Flexibility

Variable layout and modern design

Flexibility

Variable layout and modern design

  • Slim design due to narrow frieze widths

  • Large glass to frame ratio through floor-to-ceiling glazing

  • Clever technology – no hinges visible on the sash

  • Solution for sliding doors and -windows

  • Frame materials wood and wood/aluminium

Efficiency

Saves tools, material and machine time

Efficiency

Saves tools, material and machine time

  • Modular construction principle for various material concepts

  • Same basic profiles as for standard market wood/aluminium window systems

  • Optimization for single part production on CNC machining centres

Sustainability

Future-proof, long-lasting and environmentally friendly system

Sustainability

Future-proof, long-lasting and environmentally friendly system

  • High density due to horizontal closing mechanism for optimum seal pressure

  • Maximum handling comfort and high functionality

  • Tested elements


Leitz ClimaTrend

A system for the highest of demands

Leitz ClimaTrend

A system for the highest of demands

With the tested ClimaTrend system from Leitz, both wood and wood-aluminium systems can be produced flexibly and economically. The construction is available in wood thicknesses IV68 to IV106 and have future-proof technical features in the areas of thermal engineering, noise protection and safety.

Leitz ClimaTrend
ClimaTrend

Flexibility

Modular system design

Flexibility

Modular system design

  • Design as wood or wood/aluminium system

  • Different wood thicknesses from IV68 to IV106 possible

  • Can be manufactured on all conventional machines to CNC throughfeed machines

Reliability

Tested against driving rain, burglary and wind load

Reliability

Tested against driving rain, burglary and wind load

  • Increased performance compared to conventional systems by increasing the distance between the wind and rain barrier to 32 mm

  • Wood thicknesses IV68, IV78 (80) and IV90 (92), IV106 and 13 mm fittings provide security

Sustainability

Thermal insulation and noise protection

Sustainability

Thermal insulation and noise protection

  • With the IV78, 3 functional window panes up to 40 mm can be used as standard

  • Panes up to 52 mm thick can be used with the IV90

  • Best value Uw = 0,76 W/(m²K) for wood thickness IV90


Leitz PlugTec

The stable frame corner joint for windows and doors

Leitz PlugTec

The stable frame corner joint for windows and doors

PlugTec, the corner joint from Leitz, combines the advantages of conventional joints in one system. Due to the dowel-less production on CNC machines, the production is efficient and cost-effective and the application is flexible. With its approval for the highest weight class of 180 kg, PlugTec is an ideal solution for window manufacturers, architects and building owners.

Leitz frame corner joint PlugTec
Frame corner joint PlugTec

Quality

Outstanding stability

Quality

Outstanding stability

  • Tested and approved for sash weights up to 180 kg, from a wood thickness of 78 mm (Testing Institute IFT Rosenheim)

  • Precise and form-fit frame corner joints by using milled slots and tenons

  • Significantly higher load-bearing capacity than conventional corner joints such as counter/dowel or slot/tenon joints

  • Optimal solution for particularly narrow frieze widths

Efficiency

Time-saving production

Efficiency

Time-saving production

  • Cost-effective production in one workpiece clamping on the machine

  • Material savings due to no additional connecting elements

  • Saves time by shortening the entire production process

  • Optional saving of the frame press by using of a screw connection for the gluing process

Flexibility

Variable application

Flexibility

Variable application

  • Applicable in almost all windowand door systems

  • Can be used on all conventional window CNC machines
